• <p>NESSy MEDUSA</p>

Overview

NESSy MEDUSA

Double power on energy efficiency

By using the NESSy MEDUSA lance you double the snow production per snow making point.

  • 80% compressed air consuption compared to conventional snow lances
  • Start snowing at -1.5°C wet bulb temperature
  • Fewer noise emissions
  • Without additives

By using the NESSy MEDUSA lance you double the snow production per snow making point. This is irrespective of the wet bulb temperature! Espacially the high performance in the arginal temperature range makes your snow making system ven more effective.

Given the increasingly scarce time-frames for artificial snow production, the productivity of the snow making system is crucial! This is point where the double-head lance comes into its own.

NESSy MEDUSA builds on proven technology:
  • Variable lance construction
  • Single or multi-stage lances
  • Existing lances can be converted easily

Technical data

Lance lengths10m, 8.5m, 7m, 5m
Type of controlmanual, automatic, fully automatic
Snowing levels4
Weight incl. lifting device175 kg (at 10 m Lance length)
Energy requirement1.7 kW (central air), 2.2 kW (Onboard-Compressor)
Air supplymax. 300 Nl/min at 10 bar
Water flow rate60 to 468 l/min
Working pressure15 - 60 bar
Throw5 - 20 m
Noise level61.2 dB at 20 m
Fast change system BTTavailable, for optimized handling
Nozzle assembly2 heads with each 9 water- and 3 nucleator-nozzles
Start marginal temperature-1.5° WBT
Maximum performance from-8° WBT
Snowing performance8 up to 63 m³/h
Specific snow weight400 - 450 kg/m³, adjustable
FoundationPit constructions, Concrete- and Screw-Foundations, Mobile solutions
Retrofit/Conversioneasily possible, for existing Bachler lances as well for other providers

Snow cover map and Snowspider

Baechler Top Track NESSY MEDUSA 01 Baechler Top Track NESSY MEDUSA 03 EN

Suitable supplies

Pit Solutions

The ingenious pit components can be assembled on your demand. Thereby it provides endless opportunities to design the system inexpensive and user-optimised.

Combi-Pitvale

The very compact combi-pitvalve with combined control of water and air in the basic is perfectly suited for use with NESSy/SnoTek.

Hydrant handler

The handler is applicable for nearly all common hydrants through the exchange of the shaft adapter.

Compressor

The compact and quiet compressor, which is installed in a box of aluminium, feeds a NESSy or SnoTek with sufficient compressed air.

Snow and transport hoses

Our approved and high quality heavy-duty snow hose for low-pressure, high-pressure and lance-snowmaking-systems.

Base Frame Mobile

The installation of the base frame occurs before winter with a wheeled vehicle on the mounted wheels or with a snow groomer on the snow.

Slewing drive

The slewing drive is used for the optimal area width snowmaking.

Fully automatic system BTT

The fully automatic system, which is developed specifically for Bächler snowmakers, is characterised by the excellent adjustment with the optional components.
